Technische Beschreibung

• RAHMEN

  Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, Comfort Flat chainstays (Flatstays) design
• Gabel

  Fox 32 29 Float GRIP EVOL Rhythm, 100mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: remote 2pos Push-unlock, low-speed rebound, air preload, Remote Fox single pull
• Federweg vorne

  100 mm
• Schaltwerk (hintere Schaltung)

  Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
• Bremse vorne

  Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Bremse hinten

  Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
• Bremshebel

  Sram Level, tooled reach adjust, lever pivot bushings
• Kurbel

  Truvativ Stylo 6K Eagle, 12s, Boost, DUB axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm, Rings 34T, steel, X-Sync 2
• Tretlager

  Sram DUB BSA, sealed bearings, 73mm
• Kopfhörer

  ONOFF Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º
• Patrone

  Sram XG-1230, 11-50T, 12s
• Kette

  Sram SX Eagle, 12s, Powerlock
• Lenker

  ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore
• Vorbau

  MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: size S: 60mm, size M: 70mm, size L: 80mm, size XL: 90mm
• Sattelstütze

  ONOFF Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm
• Sattel

  Mondraker XC Series, steel rail
• Fahrradgriffe

  ONOFF Twin, 1lock-on, 135mm
• Vorderradnabe

  Mavic, Boost 15x110mm, IS 6 bolts
• Hinterradnabe

  Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts
• Felgen

  Mavic Crossmax 29, 25mm internal width, welded rim, hookless, tubeless ready, 24 spokes - Mavic straight-pull double butted, contactless lacing
• Reifen

  Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead
• Radgröße

  29"
• GEWICHT

  10,8 kg

Weiteres

• Produktcode

  N23000810
